Description
Protection Level : IP66
Image Sensor : 2.4 MP CMOS
Signal System : PAL/NTSC
Frame Rate PAL : 25fps NTSC: 30fps
Min. Illumination 0.01 Lux @ (F1.2, AGC ON), 0 Lux with IR
Shutter Time PAL : 1/25 s to 1/50, 000 s NTSC: 1/30 s to 1/50, 000 s
Lens : 4 mm or 6 mm fixed lens
Horizontal Field Of View : 106.4° (2.8 mm), 79.6° (3.6 mm), 51.9° (6 mm)
Lens Mount : M12
Day & Night : ICR
WDR (Wide Dynamic Range) : Digital WDR
Angle Adjustment Pan: 0° to 360°, Tilt: 0° to 75°, Rotate: 0° to 360°
Menu
Image Mode : STD/HIGH-SAT
AGC : Support
Day/Night Mode : Auto/Color/BW (Black and White)
White Balance : Auto/Manual
HLC : Yes
BLC (Backlight Compensation) : Yes
Language : English
Functions : Brightness, Sharpness, Mirror, Smart IR
Interface
Video Output : Switchable TVI/AHD/CVI/CVBS or Non Switchable
General
Operating Condition : ‘-40 °C to 60 °C (-40 °F to 140 °F), Humidity: 90% or less (non-condensation)
Power Supply : 12 VDC ± 25%
Power Consumption : Max. 2.5 W
Material : Enclosure Plastic Main body
IR Range : Up to 20 m
